HQQ-2500 Infrared Bridge Multi Blade Cutter
With reliable mechanical transmission, sealed oil-immersed track, automatic slicingdevice lead screw protective lifting system, the machine is your reliable stable.efficient block cutting sol. Easy installation and simple maintenance No trolley orworking table needed.
PRODUCT FEATURES
◆ Robust Construction：
Lifting mechanism crafted from high-quality gray cast iron, offering wear resistance, minimal deformation, and easy maintenance.
Critical components utilize imported premium parts for enhanced durability.
◆ Precision Cutting & Automation：
Variable-speed feed control (left/right motion) via frequency converter, adjustable for different stone materials.
Hydraulic lifting system (optional screw lifting) for smooth vertical adjustment.
Automatic forward/backward splitting with high-precision ball screw drive for accurate slab separation.
◆ Efficiency & Stability：
Direct ground placement of raw blocks eliminates the need for trolleys, reducing maintenance costs.
High productivity with exceptional cutting precision, stability, and operational simplicity.
Superior slab flatness for premium-quality output.
◆Ideal Application:Specially designed for cutting high-value granite and marble blocks, ensuring optimal results for demanding stone processing.
TECHNICAL PARAMETER
Item | unit | HQQ-2500 |
| Blade diameter | mm | 2500 |
| Max cutting size | mm | 3000*2000*1000 |
| Blade up and down stroke | mm | 3200*2000 |
| Max.No.of blades | pcs | 3 |
| Main motor power | kw/hp | 37/50.36 |
| Water consumption | m³/h | 4 |
| Gross weight | Kg | 9700 |
| Overall dimension | mm | 4500*3000*2300 |
MACHINE DETAILS
